SPECIALIZED
Diverge 4 Pro
Diverge 4 Pro
SKU:95426-1056
In stock
Product Sold Out? Contact us and we will try to find it for you.
Couldn't load pickup availability
Read More
Read More
The Ultimate Getaway Vehicle
Race-tuned. Adventure-approved. The Diverge 4 gravel bike is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and the biggest internal storage in gravel, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.
At a Glance
Use: Gravel Adventure/Race
Frameset: FACT 9r Carbon
Suspension: Future Shock 3.3
Drivetrain/Wheels: SRAM Force AXS XPLR / Roval Terra CL
Storage: SWAT 4.0
Weight: Diverge Pro: 8.39kg
Share

Technical Specifications
Frameset
Frame: Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
Fork: Future Shock 3.3 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc
Brakes
Front Brake: New SRAM Force E1, hydraulic disc
Rear Brake: New SRAM Force E1, hydraulic disc
Drivetrain
Shift Levers: New SRAM Force AXS E1
Rear Derailleur: New SRAM Force AXS E1 XPLR
Cassette: New SRAM Force E1 XPLR 10-46t, 13sp
Chain: New SRAM Force XPLR, 13sp
Crankset: New SRAM Force E1 XPLR, DUB WIDE, 40t, Quarq Power Meter
Bottom Bracket: SRAM DUB BSA 68 Wide
Wheels & Tires
Front Wheel: Roval Terra CL Rim, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Front Tire: Tracer 700x45, Tan Sidewall, Tubeless Ready
Rear Tire: Tracer 700x45, Tan Sidewall, Tubeless Ready
Rear Wheel: Roval Terra CL Rim, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Inner Tubes: Presta, 700x32-50mm
Cockpit
Stem: Specialized Pro SL, alloy, 4-bolt
Handlebars: Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Tape: Supacaz Super Sticky Kush
Saddle: Power Pro Mirror, Hollow Ti rails
SeatPost: Roval Terra Carbon Seat Post, 20mm Offset
Seat Binder: Specialized Alloy, 30.8mm
Accessories
SWAT: SWAT 4.0 internal downtube storage
Product Details
Product ID: 293747
Weight
Weight: 8.39 kg (18 lb, 7.9 oz)
Weight Size: 56
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Stem Length | 60mm | 70mm | 80mm | 90mm | 100mm | 100mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 330mm | 330mm | 380mm | 380mm | 380mm | 380mm |
| Stack | 563mm | 578mm | 592mm | 610mm | 634mm | 659mm |
| Reach | 365mm | 374mm | 387mm | 400mm | 412mm | 425mm |
| Head Tube Length | 90mm | 104mm | 116mm | 135mm | 161mm | 187mm |
| Head Tube Angle | 70° | 70.5° | 71° | 71° | 71° | 71° |
| BB Drop | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm |
| Trail | 72mm | 68mm | 65mm | 65mm | 65mm | 65mm |
| Fork Length, Full | 391mm | 391mm | 391mm | 391mm | 391mm | 391mm |
| Fork Rake/Offset | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm |
| Front Center | 604mm | 613mm | 626mm | 645mm | 665mm | 686mm |
| Chainstay Length | 430mm | 430mm | 430mm | 430mm | 430mm | 430mm |
| Wheelbase | 1019mm | 1031mm | 1041mm | 1060mm | 1081mm | 1102mm |
| Top Tube Length, Horizontal | 521mm | 537mm | 556mm | 575mm | 593mm | 613mm |
| Bike Standover Height | 700mm | 725mm | 754mm | 779mm | 805mm | 832mm |
| Seat Tube Length | 400mm | 430mm | 470mm | 500mm | 530mm | 560mm |
| Seat Tube Angle | 74.5° | 74° | 74° | 74° | 74° | 74° |
Size Guide
