Roval Terra Aero CLX

Roval Terra Aero CLX

30026-6212

R 40,000.00
R 40,000.00 R 40,000.00
Sale Sold out
Vat Included
Option

Out of Stock In Store

Product Sold Out? Contact us and we will try to find it for you.

  • Visa
  • Mastercard

Read More

Terra Aero CLX

Gravel racing now demands the same level of aerodynamic discipline historically reserved for World Tour races. Riders are pushing deeper into speed ranges where aero drag matters—and they’re doing it on rougher terrain with bigger tires. Up to 5.84 watts faster than the previous generation, with a first-of-its-kind 50mm Chopped Aero Speed design.

At a Glance

Use

  • Gravel Racing

Weight

  • 1,340g with tape & valves

Rim Depth & Width

  • 50mm / 45mm F/R external, 38.5mm internal width

Hub & Engagement

  • DT Swiss 180 EXP internals, 36T

Spokes

  • Roval Aero Composite Spokes by ARRIS
View full details

Technical Specifications

Rims

Front Rim

Terra Aero CLX Carbon Clincher, 700c (CR2570)

Front Rim Dimensions

Depth: 50mm, External Width (at widest point): 38.5mm, Internal Width: 27mm, Bead Hook Width: 5.38mm

Rear Rim

Terra Aero CLX Carbon Clincher Rear, 700c (CR2571)

Rear Rim Dimensions

Depth: 45mm, External Width (at widest point): 38.4mm, Internal Width: 27mm, Bead Hook Width: 5.38mm

Rim Construction

Carbon Clincher Hooked

Wheel Size / ETRTO

622 × 27 (700c)

Hole Count

Front: 18H, Rear: 24H

Tubeless Compatibility

Yes

Insert Compatibility

Yes

Brake Compatibility

Disc (Centerlock)

Valve Stem Length

Roval Tubeless Valve, Alloy 70mm (Front) 60mm (Rear)



Hubs

Front Hub

Roval Low Flange Road Hub, Center Lock, 12x100mm, 19mm OD End Caps Installed (LF18-F)

Rear Hub

Roval Low Flange Road Hub, Center Lock, 12x142mm, (LF19-R)

Front Hub Bearing

DT Sinc Ceramic Bearings - DS: 6802 (15 x 24 x 5mm), NDS: 6802 (15 x 24 x 5mm)

Rear Hub Bearing

DT Sinc Ceramic Bearings - DS:1526 (15 x 26 x 7mm), NDS: 6802 (15 x 24 x 5mm)

Rear Freehub Body

DT Swiss Ratchet EXP (36T ): Sram XD-R



Spokes & Nipples

Front Spokes

Roval by ARRIS, Composite Aero Spoke with Ti End Pieces: T-head, 18qty, (DS: 264mm, NDS: 274mm)

Rear Spokes

Roval by ARRIS, Composite Aero Spoke with Ti End Pieces: T-head, 24qty, (DS: 280mm, NDS: 276mm)

Front Lacing Pattern

Two-Cross / Radial (2:1), Not Tucked

Rear Lacing Pattern

One-Cross / Three-Cross (2:1), Not Tucked

Nipples

ARRIS MK4 Spoke Nipple Alloy, 6mm



Tire Info

Approved Tire Widths

35mm-60mm (2.2")

Max Pressure

35mm – 70psi​, 36-45mm – 55psi​, 46-50mm – 45psi​, 51-60mm - 40psi

Tire Type

Clincher Tubeless and Clincher Tube Type

Tubeless Tape Width

30mm

Design Tire

Tracer TLR 45mm



Weight

Front Weight

640g (with valves and tape)

Rear Weight

700g (with valves and tape)

Wheelset Weight

1340g (with valves and tape)



General

Extras

4 Extra Spokes and Nipples, Roval Wheel Bag, Shimano HG 11/12-Spd. Road Freehub & end Caps (rear wheel only)

E-bike Approved

No

Certifications

ISO 5775-2, UCI Approved

Weight Limit

275 lbs / 125 kg

Assembly Method

Hand Built
